AIDA ENGINEERING,LTD.

Products

Servo Press icon

DSF-N1-A Series

Product Information

AIDA

DSF-N1-A Series

AIDA Direct Servo Formers DSF-N1-A Series

We have added a highly rigid straightside frame model to our lineup of evolved A-Series servo presses.

- Equipped with AIDA’s own low RPM, high torque servo motor-the most advanced in the world

- A direct drive structure which makes full use of the flexible control of a servo press

- In addition to the three evolutions of "productivity," operability," and “energy saving" incorporated into our new A-Series Direct Servo Former, the N1-A Series is equipped with two additional features.

- The frame shape has been redesigned, and the bolster rigidity has been boosted 50%※1 compared to previous models.

- The service life of electrical components is extended by housing them in a cabinet that is isolated from the frame.（※1Compared to previous AIDA servo presses.）

Advantage

Equipped with AIDA’s own low RPM, high torque servo motor.Able to process high-added value products with high precision.

Able to set the most suitable slide movement mode and restore it in the database according to the shape of products even if the materials are difficult-to-form.

Equipped with manual step feed, making die matching and die adjustment easier.
